RF coaxial adapter
|
|
|
|
Temperature Range
|
-55~+155°C (PE Cable -40~+85°C)
|
|
|
Impedance
|
50Ω
|
|
|
Vibration
|
100m/S2 (10~500Hz), 10g
|
|
|
Frequency Range
|
DC-18GHz
|
|
|
Insertion Loss
|
≤ 0.24dB/18GHz
|
|
|
Withstanding Voltage
|
2500V r.m.s at sea level
|
|
|
Working Voltage
|
1000Vr.m.s at sea level
|
|
|
Insulation Resistance
|
≥ 5000 MΩ
|
|
|
Center conductor retention force
|
450N
|
|
|
Durability
|
≥ 500(cycles)
|
|
|
Contact resistance
|
CenterContact ≤1mΩOuter Contact ≤1mΩ
|
|
|
Voltage Standing Wave Ratio
|
Straight ≤ 1.15/6GHzRight angle ≤ 1.25/6GHz
|
|
|
4.3/10 Female Jack soldering RF coaxial Connector For 1/2" Foam Superflexible wiring Cable
|
|
|
|
Body
|
Brass
|
Nickel plated / Gold plated
|
|
Inner Pin
|
Inner Pin
|
Brass
|
|
Resilient Contact
|
Resilient Contact
|
Beryllium Copper
|
|
Socket Contact
|
Socket Contact
|
Beryllium or tin bronze
|
|
Insulator
|
Insulator
|
PTFE
|
|
Crimp Ferrule
|
Crimp Ferrule
|
Copper alloy
|
|
silasticO-ring sealing
|
silasticO-ring sealing
|
silastic
|
Zhenjiang Woshuang RF Technology Co., Ltd. – A leader in RF solutions. We have established end-to-end capabilities from R&D to after-sales service.
Core Competencies and Advantages: Comprehensive RF Product Portfolio:Adapters, connectors, antennas, coaxial cables, surge protectors, and passive components;
Flexible Customization:
OEM/ODM solutions, including rapid prototyping, parameter selection, performance testing, and system optimization, meeting the stringent application requirements of industries such as telecommunications, and aerospace;
Technical Strength:
Experienced R&D team and standardized laboratories provide one-stop service from prototype development to mass production;
Quality Assurance: Strict adherence to ISO/IEC international standards ensures that products achieve industry-leading levels in weather resistance, signal stability, and other key indicators;
Global Service Network: Experienced engineers provide 24/7 technical support, real-time consultation, and troubleshooting. Our products are widely used in cutting-edge applications including 5G base stations, satellite communications, and smart IoT, with customers worldwide, covering 30 countries and regions in Europe, the Americas, Asia Pacific, and other regions.
Q1: How to deal with the quality of goods? A1: Please contact us, we will provide technical services and support throughout the process. Q2: Will you guide the use and installation? A2: Of course, we will provide technical support and remote guidance throughout the process. Q3: What payment methods do you support? A3: Common payment methods include: T/T,L/C,D/P D/A,Money Gram,Credit Card, PayPal, Western Union,Cash，Escrow. Q4: What transportation methods do you have? A4: We have sea freight, air freight, express delivery, railway, road, and multi link transportation. Q5: Can you do design for us? A5: Yes, we do OEM and ODM service. We have good experience development. Q6: What types of connectors do you have? A6: We have common models such as N, SMA, SMB, SMC, BNC, TNC, QMA, SMP, UHF, 4.3/10,7,16DIN, HN, LC, 10/32, F, MCX, NEX-10CRC9, U.FL, EIA flange, etc. We also customize production according to customers' special needs. Q7: What types of cables do you have? Q7: We have RG cable, Low Loss cable,Semi-Rigid Cable,Hand Formable cable,Mini-Coaxial cable,Flexible Test cable,Corrugated Cable, There are also other special types of cables. Q8: How to choose connectors correctly? A8: Consider the following aspects: interface mechanism type, characteristic impedance, cable connection method and cable type, termination form Select connectors based on specific usage scenarios and frequency ranges for signal transmission Q9: How to judge the quality of coaxial connectors? A9: The quality of coaxial connectors requires comprehensive consideration of electrical performance, mechanical performance, materials and coatings, environmental adaptability, as well as certification and standards. Q10: Can cables be purchased according to size? A10: Of course, we will produce according to the customer's needs. Specific size requirements can be obtained by contacting us, and we will provide you with the most suitable solution and price. Q11: I don't know what type of connector/cable I need? A11: Don't worry, , you can send us photos or specifications of your product, and we will have professional engineers to follow up. We can also make samples and customize products.
